Labs

This is my Lab corner, here you can find my Labs for different technologies. You can find my Labs on my Github, since VIRL allows you to import your repo using Git, it makes my life easier.

https://github.com/rubenongit

Finally Cisco VIRL in 2 flavours

It´s official! Cisco launches VIRL, so you can run virtualized versions of IOSv, IOS XRv, NX-OSv and CSR1000v. It´cames in 2 Flavours plus 2 different Gift Cards :)

virl_ver

VIRL Personal Edition is capped at a maximum of 15 Cisco VMs. You can run more non-Cisco VMs, assuming that you have sufficient memory and CPU.

Educational pricing is available for this product for college students, parents buying for a college student, or teachers, homeschool teachers and staff of all grade levels – limited to one purchase.

VIRL enables users to:

• Build highly-accurate models of real-world or future networks.

• Learn and test with ‘real’ versions of Cisco network operating systems – IOSv, IOS XRv, NX-OSv and CSR1000v.

• Integrate virtual network simulations with real network environments.

• The download includes VIRL Personal Edition 1.0 Pre-Release software with a single-user annual license to manage up to 15 Cisco nodes.

The memory requirements for each VM type can be seen via VM Maestro by selecting a node on your canvas, opening the ‘properties’ panel and pressing the ‘Browse’ button under ‘Node/VM Flavor’.

VIRL requires communication with the Cisco salt-master servers in order to complete the software installation but after that has been completed, VIRL will attempt to check in with the Cisco salt-masters automatically. If it communicates with the Cisco salt-masters successfully, you are given a ‘7 day license’ enabling you to operate ‘off net’ for up to 7 days.

You must purchase and install one of the following supported Hypervisors in order to run Cisco VIRL.:

• VMware Fusion Pro v5.02 or later (including v6.x or v7.x)

• VMware Workstation v8.04 or later (including v9.x and 10.x)

• VMware Player v5.02 or later (including v6.x)

• ESXi 5.1 / 5.5 using the vSphere Client: ESXi 5.1U2 (Build 1483097) or ESXi 5.5U1 (Build 1623387)

Here’s the summary:

IOSv = 1vCPU, 512Mb
IOS XRv = 1vCPU, 1536Mb
CSR1000v = 1vCPU, 3096Mb
NXOSv = 1vCPU, 2048Mb

You can view a short demo of the product in the link below.

Presentation of Cisco VIRL at Cisco Live



Refereces:

Introducing Virtual Internet Routing Lab
